Series Resonant Test System

Series Resonant Test System
Series Resonant Test System
Product Code : 15
Product Description

Being a customer-centric organization, we bring forward the world-class Series Resonant Test System with alterable inductance and module kind. The type of test system is utilized for factory testing of high and medium voltage cables, high voltage capacitors, arresters, generators, power transformers and high voltage accessories. They comprises stackable modules that can be utilized for testing a large spectrum of products. It can be expandable in order to cover future test needs that may need higher power and voltage level. We offer the Series Resonant Test System to clients at negotiable prices.

Features & Benefits:

  • Lowest PD noise level;
  • Pure AC sine wave at output;
  • Low input power demand due to high quality factor;
  • Highest voltages by cascading of several modules;
  • Multiple Q valuesto meet a variety of applications;
  • Large variety by single, series and parallel circuits;

Applications:



  • AC bear test on cables and cable accessories;
  • AC withstand tests on generators, GIS, capacitors and motors;
  • Applied voltage tests on transformers;
  • HV tests on current and voltage transformers;
  • Partial discharge testing
  • Bushing testing;

Technical Parameters:

Model No.

Maximum Output Voltage

Output Current

PD Level

(kV)

(A)

JXXZ-2800/70

70

40

<5pC

JXXZ-340/85

85

4

<5pC

JXXZ-1000/100

100

10

<5pC

JXXZ-2250/100

100

22.5

<5pC

JXXZ-2400/120

120

20

<5pC

JXXZ-2640/220

220

12

<5pC

JXXZ-2500/250

250

10

<5pC

JXXZ-5250/350

350

15

<5pC
